NON-METALLIC

PE Sintered Filter Cartridge

Activated Carbon Filter Cartridge Series: Manufactured from high-quality, high-efficiency activated carbon fine particles combined with food-grade binders. Utilizing advanced technology and special high-temperature sintering processes, it integrates adsorption, filtration, interception, and catalytic functions, offering dual filtration and purification capabilities.Effectively removes organic compounds, residual chlorine, and radioactive substances from liquids or gases, while also decolorizing and eliminating odors. This product retains the superior adsorption properties of granular activated carbon while avoiding the drawbacks of loose activated carbon, such as carbon powder release. Activated carbon filter cartridges are widely applicable for purifying process water and solutions in sectors including semiconductors, electronic components, printed circuit boards, electroplating, and food & beverage industries.

Market Standard Precision: 5μm

INQUIRE NOW

NEXT PRODUCT

OVERVIEW

SPECIFICATIONS

Core Features

Activated carbon filter cartridges feature a true deep-bed structure with dual filtration and purification functions. Their rich pore structure provides excellent adsorption characteristics.

Effectively removes residual chlorine, odors, and organic compounds.

Low pressure drop ensures stable water flow.

Manufactured using specialized processes for superior sealing without carbon powder release.

Applications

Electronics Industry: Filtration for semiconductors, electronic components, printed circuit boards, pure water, gases, and electroplating solutions.
Chemical & Petrochemical Industry: Filtration for organic solvents, coatings, magnetic slurries, detergents, and liquid waxes.
Pharmaceutical Industry: Filtration for hospital water, pharmaceutical injections, traditional Chinese medicine preparations, and oral liquids.
Food Industry: Filtration for food, beverages, drinking water, mineral water, alcoholic beverages, etc.

Specifications	Inner Diameter	Outer Diameter	Length	Water Treatment Capacity	Filter Precision	Packaging
5-inch	28/30mm	65mm	127mm	0.25 t/h	500-1100 mg/g	100 cartridges/box
10 inches	28/30mm	65mm	254mm	0.5 t/h	500-1100 mg/g	50 pieces/box
20 inches	28/30mm	65mm	508mm	1 t/h	500-1100 mg/g	25 pieces/box
30 inches	28/30mm	65mm	762mm	1.5 t/h	500-1100 mg/g	20 pieces/box
40 inches	28/30mm	65mm	1016mm	2 t/h	500-1100 mg/g	20 pieces/box
